BS100 3″ LCD BORESCOPE INC AV OUTPUT
Features
- Real-time Live view
- TV-OUT for connection to larger monitor
- Bright LED for operation in dark locations
- Built-in 2000mAh lithium battery, charged via USB
- Charges while in standby
- Allows 180° rotating of the image
- Adjustment of contrast, brightness, color temperature, etc. via OSD
- Language: English and German
Accessories
- Hard Carry-case
- User Manual
- AC Power Adapter
- 5VDC / 1A – USB Port output
- USB Charging cable
- 3.5mm to RCA Video Cable
- Camera Attachments
- Mirror Attachment ×1
- Hook Attachment ×1
- Magnet Attachment ×1
Specifications
| Camera | Sensor | 1/4 inch CMOS |
|---|---|---|
| Num Pixels | 300,000 | |
| Maximum Resolution | 640 × 480 | |
| Maximum Frame Rate | 30fps | |
| Colour Depth | 24 Bit | |
| Focus | Fixed focus; 15cm ~ 25cm (5.9~9.8") |
|
| Diameter | 17mm (0.66") | |
| Gooseneck | Length | 1m (39") |
| Display | Size | 3.0" |
| Type | TFT-LCD | |
| Resolution | 960 × 240 | |
| Active Area | 60mm × 45mm | |
| Lighting | LEDs | ×4 |
| Brightness | Adjustable: 6 levels | |
| Power | Battery | Lithium battery 3.7V / 2000mAh |
| Working Current | 480mA (max) | |
| Standby Current | 5mA (max) | |
| Mechanical | Operating Temperature | 0°C – 50°C |
| Storage Temperature | -20°C – 60°C | |
| Relative Humidity | 5% – 85% | |
| Dimensions | 100 × 95 × 235mm | |
| Weight | 596.2g |
