TV ANTENNAS & SATELLITE, TV ANTENNA ACCESS.

2 WAY ‘F’ SPLITTER FREE TO AIR

00845434

|

FSP2F

2-Way 75andOmega; coaxial splitter

5~900MHz Splitters with power pass on one leg

Metal shielded case with “F” type sockets

    2 WAY ‘F’ SPLITTER FREE TO AIR
  • Description
  • RESOURCES

    • Description

    View Similar

    product1
    5-694MHZ 4G ANTENNA FILTER
    product1
    12V DC 300mA POWER SUPPLY

    DESCRIPTION

    • 2-Way 75 ohm coaxial splitter
    • 5~900MHz Splitters with power pass on one leg
    • Metal shielded case with "F" type sockets

    Specifications:

        FSP2F FSP3F FSP4F FSP6F FSP8F
      Frequency Range(MHz) Nominal Nominal Nominal Nominal Nominal
    Insertion Loss 5-47MHz 4.2 5.8 8.2 11.5 12.5
    (Max dB) 48-450MHz 4.2 5.8 8.2 11.5 12.5
      451-750MHz 4.2 6.5 8.2 11.5 12.5
      751-900 MHz 4.2 7 8.2 11.5 12.5
    ISOLATION 5-47MHz 20 20 20 20 20
    Out-out 48-450MHz 20 20 20 20 20
    (Min dB) 451-750MHz 20 20 20 20 20
      751-900 MHz 20 20 20 20 20
    Return Loss 5-47MHz 18 18 18 16 18
    Input 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16
    Return Loss 5-47MHz 18 18 18 16 18
    Output 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16



    Note:
    Doss splitters will also function as combiners.
    • When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
    • It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.
