43150267
|IN30AHDS
HD AHD, CHD, THD/1080p, analog 1280H, 4-in-1 output
3.6mm M12 Lens
Video coaxial transmission distance up to 500m
CAMERA | ||
Sensor | 1/2.7" 2M pixels CMOS | |
Effectivepixels | 1920*1080 | |
HDAHDoutput | 1080P | |
Resolution | 1280H(CVBSinput) | |
Min.Illumination | 0Lux(IRON) | |
SyncSystem | Internal | |
Lens | 3.6mmM12lens | |
ElectronicShutter | Auto/Manual(X30~1/50000)/FLK | |
S/NRate | ≥50db(AGCOFF) | |
Videooutput | 1.0Vp-pcompositevideooutput,75O | |
outputmodel | PAL/ NTSCadjustable | |
OSDmenu | ||
Whitebalance | ATW/ AWC-SET/ INDOOR/ OUTDOOR/ MANUAL/ AWB | |
NR | 2DNR | |
Imageadjustable | Brightness,sharpness,AGC | |
DWDR | AUTO/ ON/OFF | |
BLC | BLC/HsbLC/OFF | |
General | ||
Transmissiondistance | 75 - 3/ 300m, 75 - 5/ 500m | |
IRdistance | 20-30m(30 x Ø5IRled) | |
powersupply | DC12V ±10% | |
Power consumption | <5W((IR leds +main board: 0.96W) | |
OperatingTemperature | −20°C~55°C/0%-90% | |
Weight/ PC(g) | 600g | |
Expecting AHD but only getting Composite?
Our AHD cameras come out of the box configured to output Composite (CVBS) to allow installers with test monitors to quickly align the camera. Once positioned correctly, you can set the camera to AHD output using the setting shortcuts below:
