DESCRIPTION

Features

The DOSS HD8200VPDM is an active high definition digital signal extender solution (Repeater Only) for HD-SDI links,operating over 75Ω coaxial cable. Each unit can receive and transmit a HD-SDI high definition digital signalfrom up to 200m over coaxial cable. It can be used with multiple repeaters to extend distance up to 1km.

Applications

• Security Monitoring System
• Multimedia Network Teaching System
• Medical Monitoring Display System
• Industrial Automation Control System
• Banking, securities, financial information display system
• Remote Network Server Monitoring
• Department Store Security
• Casino Security
• Hospitals, Airports and banks
• School

Features

• Compatibility: compatible with HD-SDI and SD-SDI signal
• Transmission Distance: 0-200m (HD-SDI 1.485Gbps)
• Characteristics: Automatically clock recovery caching processing technology
• In conjunction with multiple repeaters, the distance can up to 1km max
• Automatically fit the SMPTE and ITU digital video standard
• High interference suppression, anti-surge technology
• Support high-definition HD-SDI digital video at 720p60, 1080i60 and 1080p30 formats at all frame rates
• Integrated cable equalizer for long distance video transmission without quality loss
• High-quality digital video and audio transmission withnearly zero latency

Application Diagram

Typical Application

Click for larger image

Installation Notes

• The HD8200VPDM Repeater requires power from the Receiver unit (HD8200VPDR) and will not operate without power.
• Minimum system installation is the Receiver + Transmitter pair—use the Repeater unit to extend basictransmission distance
• Will not operate independently
