DESCRIPTION

Features

DOSS DMZ150IPWV3 camera enables you to keep an eye on your territory 24/7! It has a 2MP camera for clear image taking or recording as well as tilt and zoom in functions. The area scan function provides routine scanning of the areas of your choice, non-stop unless you told it to. Easy setup and easy control, powered by POE mean no more hassle for wiring power cable!
Thanks to the Sony Starvis technology, the low light performance will bring your security experience up to another level. Check out the comparison video from the video tab above.
The new version now comes with an optional H.265 encoder feature, which offers massively improved compression over H.264 with the file size and bit rate.

Features

• 1/2.8"Sony 2.13M IMX290 CMOS Sensor
• Max 1920*1080@30fps HD video output
• H.264/H.265/MJPEG encoding
• Low illumination 0.22Lux/F1.6(Color), 0.002Lux/F1.6(B/W), 0 Lux(IR on)
• 23X 2MP UHD optical zoom and 16X digital zoom
• Autofocus lens 4.7mm - 108.1mm
• Support 3DNR, WDR, defog, HLC, anti-shake, etc
• Support 360° pan endless; tilt 0°-90°
• Support manual speed: 0.1°-180°/S, preset:200°/S
• 256 presets, 4 pattern scan, 8 preset cruise
• 3D positioning, privacy mask, PTZ watch
• Smart analysis features; support target counting, objects inspection, area detection, line crossing detection
• 1CH audio input, 1CH audio output
• 2CH alarm input, 1CH alarm output, support alarm linkage
• Support smart IR grouping control, IR distance can reach 120m
• Support max 128G Micro SD card
• Slink, I8H, SDK, ONVIF, API, GB/T28181 protocol
• Lightning Protection, surging prevention, anti-surge, IP66 protection level

The STARVIS is back-illuminated pixel technology developed by Sony used in CMOS image sensors for surveillance camera applications. It features a sensitivity of 2000 mV or more per 1 µm2(colour product, when imaging with a 706 cd/m2light source, F5.6 in 1 s accumulation equivalent), and realizes high picture quality in the visible-light and near infrared light regions.

Find more info from here: https://www.sony-semicon.co.jp/e/products/I S/security/technology.html





Please note: This camera can use up to 36W via PoE+. If you're planning to use an NVR to supply PoE power for one or more of these cameras plus any other IP camera, make sure your NVR has enough PoE power to cope with the total load. If in doubt, please use an external PoE+ injector, PoE+ switch or take advantage of the AC/DC direct powering options.



What is in the box?

• DMZ150IPWV3 x 1
• Wall mount bracket x 1
• Screw bag x 1
• CD x 1
• Glove x 2

Specifications

FAQ

1. How to install the Micro SD card?
