    IP SECURITY DVR KIT - DOSS

    Professional quality 4 Channel IP DVR unit for use in thehome or office

    Allows 24hour remote monitoring through IP stream on compatible portable devices like the iphone.

    Kit includes:

    • 1x 43170800 - 4CH IPHONE COMPATIBLE NETWORKING DVR WITH VGA
    • 1x 69000030 - 500GB INTERNAL HDD
    • 2x 43150008 - 540TVL SECURITY CAMERA WITH IR
    • 2x 43150084 - 540TVL SECURITY DOME CAMERA
    • 2x 43158115 - 10MT CAMERA EXTENSION LEAD WITH VIDEO & POWER
    • 2x 43158125 - 20MT CAMERA EXTENSION LEAD WITH VIDEO & POWER
    • 1x 33774500 - 12V DC 2.5A SWITCHMODE POWER SUPPLY
    • 1x 30978204 - DC PLUG DISTRIBUTION LEAD

    FEATURES:

    • H.264 (main profile)/ MJPEG video compression
    • Support 1/4ch playback simultaneously
    • Support multiplex, PPPoE, DHCP, SATA HDD.
    • Support USB2.0 backup, dual stream bit
    • Integrated web server for access via Internet Explorer
    • Email Alert - Sends log, picture, IP information to the appointed mailbox when alarm is activated
    • Built-in buzzer alarm - Configure to sound a warning when motion is detected or video signal is lost
    • Auto-recovery capability after powering on
    • 16-bit colour menu with user friendly OSD
    • Support schedule recording, 120 preset schedule tasks
    • Search recording by time and day

    SPECIFICATIONS:

    MODEL
    DVR4CH
    Main processor Embedded High Performance processor
    Operation system Embedded RTOS
    VIDEO
    Format PAL/NTSC
    Compression H.264(main Profile)/MJPEG
    Input 4 CH, BNC(1.0Vp-P,75Ω) 　
    Output 1CH BNC(1.0Vp-P,75Ω), 1CH VGA(800×600,1024×768,1280×1204 modeloptional)
    AUDIO
    Compression

    ADPCM
    Input 4CH BNC(linear voltage,10.0KΩ) 　
    Ouput 1CH BNC(linear voltage,1KΩ)
    Intercom Support intercom 　
    DISPLAY
    Resolution D1: 704×576(PAL) 704×480 (NTSC)
    Frame rate 25(PAL)/30(NTSC)FPS
    Division 1/4CH 　
    RECORD
    Resolution CIF: 352×288(PAL)　NTSC: 352×240(NTSC)
    Frame rate 25(PAL)/30(NTSC)FPS all realtime flexible
    Quality 5 Levels (Basic,Medium,Good,High,Best)
    Mode Manual, Motion detection(support 396 grid blocks),Timing, Alarm trigger, Auto start, Pre-recording
    Video output stream 64k-2M bps adjustable
    Playback 4CH playback simultaneously
    HDD
    Basic storage 1 SATA interface,Max.2T/HDD
    ALARM
    Input 4CH 　
    output 1CH
    OTHER
    Mobile Support iPhone (AppStore link), Symbian, Windows Mobile
    System resource Multi-CH recording, playback, network operation and monitoring simultaneously
    Network RJ45, auto adapt 10/100M Ethernet, support PPPoE & DHCP
    Backup 1 USB2.0, support flash memory,Remote HDD
    Mouse 1 USB1.1 interface, support USB mouse operation
    Communication port 1 RS485 port
    Power supply DC 12V/3A
    Power(without HDD) 10W
    Weight 2.3KG
    Dimension(W×H×D) 250 x 260 x 50 mm
    Package Dimension(W×H×D) 350 x 305 x 105 mm
    Operating environment Humidity: 10~95% RH, Temperature: -10°C ~ 55°C
