16CH HYBRID 5 IN 1 NETWORK DVR

Description

RESOURCES

Description

DESCRIPTION

Features

16 CH hybrid HD 5 in 1 DVR, 2HDD position 1U case
Embedded Linux operation system, H.264 dual-stream decoding
16CH Coaxial HD+16CH IP Camera sync access
Auto recognition HDCVI/HDTVI/AHD/CVBS five mixed signal access
Support max 1/4/8/16CH sync playback and sync run backward
Support main stream and sub stream sync video
Support synchronic video, playback, remote monitoring,backup
VGA/HDMI sync output, support 1080P HD preview
Support DDNS, EMAIL, UPNP, NTP, P2P
Support WEB, mobile viewer, Client, CMS

Read our new, dedicated NVR Frequently Asked Questions page!If you're having troubles with yourNVR, perhaps you can find a solutionhere!

Specifications

Model	16CH HYBRID 5 IN 1 NETWORK DVR
VIDEO
Video Input	16CH3MP(BNC)/4main Play 8CH4MP(BNC1,3,5,7,9,11,13,15)/4main Play 16CH3MP(BNC)+16CH3MP(IPC)/ 1main Play 8CH4MP(BNC1,3,5,7,9,11,13,15)+8CH4MP(IPC)/1main Play
Video compression	H.264
Video Output Resolution	4MP/ 3MP/ 1080p/ 960p/ 720p/ D1/ 2CIF/ DCIF/ 2CIF/ CIF/ QCIF
Video Output	VGA/ HDMI sync output, 19201080, 1440900, 12801024, 1366768, 1024768, 800600
Bit Rate	16 - 8000Kbps
Image Display	1/4/6/8/9/16/20/25/36
Snapshoot	Support (JPEG)
Motion Detection	396 (22*18) surveyed area can be set in every screen and multi sensitivity adjustable
AUDIO
Audio Encoding	G.711A
Audio Input	4CH RCA
Audio Output	1 CH RCA
Talkback	--
VIDEO RECORDING AND PLAYBACK
Video Frame Rate	8CH mode: 4MP@15fps;3MP@10fps;1080P@25fps(PAL)/30fps(NTSC)real time;720P@25fps(PAL)/30fps(NTSC)real time;analog/IPC@25fps(PAL)/30fps(NTSC)real time. 16CH mode: 3MP@15fps;1080P@15fps;720P@25fps(PAL)/30fps(NTSC)real time;analog/IPC@25fps(PAL)/30fps(NTSC)real time.
Record Mode	Manual/ Timing MD/ Regular/Alarm exception/MD oralarm/MD and alarm
Playback Synchronic	Analog 4CH/Mixed 1CH main stream sync playback 4CH/8CH sub stream sync playback
Search Method	Time, Calendar, Event, Channel
Video Playback	Start, Stop, Fast play, Slow play, Frame play, Snapshoot, Full screen, Roller amplification time ball precise playback
VIDEO BACKUP
Interface	2 SATA
HDD Capacity	Single largest 6T
Backup location	Local HDD, Network
Backup Method	Network, USB storage device, USB recorder
Network Protocol	TCP/IP, HTTP, DDNS, SMTP, DHCP, PPPOE, UPNP, NTP, P2P,ONVIF
EXT INTERFACE
Network Interface	RJ45 10M/ 100M/ 1000M adaptive Ethernet port
Alarm Input	8 CH
Alarm Output	3 CH
RS-485	1 RS485
USB Port	2 USB2.0
GENERAL
Operation Temp And Humidity	-10°C ~ 55°C/10?-90?
Power supply	DC12V/5A
Power Consumption	35W(Without HDD)
Unit Dimension(mm)	L 360W 242H 48
Weight	1.5 Kg
