HEAVY-DUTY SPEAKER CABLE – 30M

• Heavy duty speaker cable, for wiring high power HI-FI speaker systems
• 2-core 96 strand/0.12 mm
  • 17AWG
  • Ø1.18mm
• 2x Plain copper conductor
  • 0.19 Ω/m
• Clear soft flexible sheath
  • 1x Round, 1x Square
  • 8.0 x 4.0mm
• Recommended max run to any HiFi speaker (min 6 ohm) is 8.5m
  • For more info, check out doss.com.au

100MM CABLE TIE 100PK

#CT100BK td { background-color: #CCF7FF }

Pack of 100 Cable Ties

Widely used in the electrical, aviation and space industries, communications and in all sorts of wiring applications.

• Nylon: Standard cable ties made from U.L. approved NYLON 6/6
  • Normal service temperature range: –10°Cto 85°C
  • Flammability rating: UL 94V-2
• Meet or exceed U.S. MIL Spec. 23190, 3367
• For dimensions, please see table below

.rpg_table { border-collapse: collapse; margin: 15px; } .rpg_table th, .rpg_table td { padding: 5px; line-height: 20px !important; } .rpg_table td, .rpg_table th { text-align: left; vertical-align: top; border-top: solid 1px #cccccc; border-bottom: solid 1px #cccccc; } .rpg_table th, .rpg_table .header { font-weight: bold; text-align: left } .rpg_table th[align=center], .rpg_table td[align=center] { text-align: center !important; } .rpg_table .spacer { border: 0 !important; width: 15px !important; } .rpg_table .no-wrap { white-space: nowrap !important; }

BROWN HOOKUP WIRE/ CABLE-1M

– 16 strands/0.25mm
– Tinned copper wire
– Insulation PVC-V105
– O/D: 1.9mm
– Amps: 3.0A
– For Electronics, Switchboards, etc.
– Colour: Brown
– Per metre
-Check 100 Metre code for quantity available.

var evExternalHTML = ‘doss-hookup’;

BROWN HOOKUP WIRE/ CABLE-1M

– 24 strands/0.2 mm
– Tinned copper wire
– Insulation PVC-V105
– O/D: 2.5mm
– Amps: 7.0A/240V
– For Mains Wiring, etc.
– Colour: Brown
– Per metre
-Check 100 Metre code for quantity available.

var evExternalHTML = ‘doss-hookup’;

RED HOOKUP WIRE/ CABLE -1M

– 32 strands/0.2 mm
– Tinned copper wire
– Insulation PVC-V105
– O/D: 3.2mm
– Amps: 10A/240V
– For Mains Wiring, etc.
– Colour: Red
– Per metre
-Check 100 Metre code for quantity available.

var evExternalHTML = ‘doss-hookup’;

BLACK TWIN POWER CABLE -1M

1 Meter 2 Core 24 Strand 0.2mm Twin Power Cable/ Black

FEATURES

WHITE TWIN POWER CABLE -1M

1 Meter 2 Core 24 Strand 0.2mm Twin Power Cable/ Brown

FEATURES

GREY TWIN POWER CABLE-1M

1 Meter 2 Core 24 Strand 0.2mm Twin Power Cable/ Brown

FEATURES

BLACK TWIN POWER CABLE-100M

2 Core 24 Strand 0.2mm Twin Power Cable/Black

FEATURES

LIGHT DUTY SPEAKER CABLE-1M

FEATURES

• Light duty speaker cable for wiring Electronic Equip.,Extension Speakers & Security Systems
• 2 corex14 strand/0.14mm
• Untinned copper conductors, Grey sheath with coloured trace
• Amperage: 1.5Amps
• Dim.: 3.6 x 1.8mm
• 24AWG
• For standard home theatre applications (i.e. min 6 ohm load), you’ll get around 2m before performance is affected. For longer cable runs, choose a larger gauge
• Sold as per meter
• For more info, check out doss.com.au

LIGHT DUTY SPEAKER CABLE-100M

FEATURES

LIGHT DUTY SPEAKER CABLE-1M

FEATURES

• Medium duty speaker cable for wiring Speaker Systems, Equipment Equip, & Security systems
• 2 core x 30 strand/0.14mm
• Untinned copper conductors, Grey sheath with coloured trace.
• Amperage: 4Amps
• Dim.: 4.8 x 2.5mm
• 100m reel
• 20AWG
• Under standard conditions, this 20AWG cable would berecommended for up to 5m (min 6 ohm load)
• Sold as per Meter
• For more info, check out doss.com.au

LIGHT DUTY SPEAKER CABLE 100M

FEATURES

MEDIUM DUTY SPEAKER CABLE -1M

DOSS 2 CORE 41 STRAND 0.16MM MEDIUM DUTY SPEARK CABLE 1METER

FEATURES

1METRE: medium duty high quality speaker cable for wiring hi-fi speaker systems.

• Medium duty speaker cable, for wiring HI-FI speaker systems
• 2-core 41 strand/0.16 mm
  • 18AWG
  • Ø1.02mm
• 1x Plain copper conductor, 1x Tinned copper conductor
  • 0.15 Ω/m
• White, soft, flexible sheath
  • 2x Round (Fig-8)
  • Printed text tracer
  • 6.0 x 3.0mm
• Recommended maximum run: 7.5 metres
• Sold as per meter
• For more information see: doss.com.au

MEDIUM DUTY SPEAKER CABLE 100M

DOSS 2 CORE 41 STRAND 0.16MM MEDIUM DUTY SPEAKER CABLE 100METER

FEATURES

100METRE: medium duty high quality speaker cable for wiring hi-fi speaker systems.

• Medium duty speaker cable, for wiring HI-FI speaker systems
• 2-core 41 strand/0.16 mm
  • 18AWG
  • Ø1.02mm
• 1x Plain copper conductor, 1x Tinned copper conductor
  • 0.15 Ω/m
• White, soft, flexible sheath
  • 2x Round (Fig-8)
  • Printed text tracer
  • 6.0 x 3.0mm
• Recommended maximum run: 7.5 metres
• Sold as per reel
• For more information see: doss.com.au

16AWG 2CORE SPEAKER CABLE 152M

16 gauge/2 core speaker cable

152m REEL with Reelex Pulling Box Technology

•
  Reelex pulling box technology – tangle-free twist-free
• Reverse metre marking
  Less scrap! See how much cable has been used and how much isleft – before you pull the cable
• Rip cord
  Makes the cable as easy to strip as possible
• Oxygen free copper
  Ensures premium sound quality in your systems. Higher purity copper means better low level signal transmission andgreat sound

Specifications

.numtype { border: 3px solid #dd5f13; width: 60px; text-align: center; font-size: 18pt; float: left; margin: 10px; } .num { border-bottom: 1px solid #dd5f13; height: 50px; font-size: 1.7em; font-weight: bold; color: #0055b8; line-height: 43px; } .type { font-size: 0.7em; padding: 5px; background: #dd5f13; color: #ccc; }

305M CAT5E SOLID CABLE BLACK

BROADBAND READY CAT-5E UTP PATCH CABLE

305M CAT5E SOLID CABLE BLUE

BROADBAND READY CAT-5E UTP PATCH CABLE

305M CAT5E SOLID CABLE GREY

BROADBAND READY CAT-5E UTP PATCH CABLE

305M CAT5E SOLID CABLE YELLOW

BROADBAND READY CAT-5E UTP PATCH CABLE

305M CAT5E SOLID CABLE GREEN

BROADBAND READY CAT-5E UTP PATCH CABLE

CAT5E STRANDED CABLE BLUE 100M

Flex-plus plenum is a high performance category 5 cable, perfect for self-terminated, custom length patch leads.

• 4 unshielded twisted pairs (UTP) 7 strand copper FEP insulated conductors
• For high speed data applications 100Mbps and beyond
• Kink resistant easy to install jacket
• Supports network systems i.e Ethernet, Token Ring and X-DDT
• Transmission distance meets or exceeds100m horiz distribution
• Attenuation: 32dB @1000ft (100MHz)

305M CAT6 SOLID CABLE BLUE

var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “Blue”; var cable_sold_as = “metre”; var cable_roll_length = “305m”;

initDossCat6();

305M CAT6 SOLID CABLE GREEN

This is the roll code. If buying by metre please click here var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “Green”; var cable_sold_as = “roll”; var cable_roll_length = “305m”;

initDossCat6();

305M CAT6 SOLID CABLE GREY

This is the roll code. If buying by metre please click here var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “Grey”; var cable_sold_as = “roll”; var cable_roll_length = “305m”;

initDossCat6();

305M CAT6 SOLID CABLE RED

This is the roll code. If buying by metre please click here var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “Red”; var cable_sold_as = “roll”; var cable_roll_length = “305m”;

initDossCat6();

305M CAT6 SOLID CABLE YELLOW

This is the roll code. If buying by metre please click here var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “Yellow”; var cable_sold_as = “roll”; var cable_roll_length = “305m”;

initDossCat6();

305M CAT6 SOLID CABLE WHITE

This is the roll code. If buying by metre please click here var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “White”; var cable_sold_as = “roll”; var cable_roll_length = “305m”;

initDossCat6();

305M CAT6 SOLID CABLE BLACK

This is the roll code. If buying by metre please click here var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “Black”; var cable_sold_as = “roll”; var cable_roll_length = “305m”;

initDossCat6();

30M RED HOOKUP WIRE/ CABLE

– 7 strands/0.25mm
– Tinned copper wire
– Insulation PVC-V105
– O/D: 1.6mm
– Amps: 1.5A
– Colour: Red
– 30 metre roll

var evExternalHTML = ‘doss-hookup’;

30M ORANGE HOOKUP WIRE/CABLE

– 7 strands/0.25mm
– Tinned copper wire
– Insulation PVC-V105
– O/D: 1.6mm
– Amps: 1.5A
– Colour: Orange
– 30 metre roll

var evExternalHTML = ‘doss-hookup’;

30M BLUE HOOKUP WIRE/CABLE

16 Strands 0.25mm Hookup Wire/Cable one Reel 100 MetersBLUE

FEATURES

• 16 strands/0.25mm
• Tinned copper wire
• Insul ation PVC-V105
• O/D: 1.9mm
• Amps: 3.0A
• For Electronics, Switchboards, etc.
• Colour: BLUE
• Per Reel

var evExternalHTML = ‘doss-hookup’;

100M BROWN HOOKUP WIRE/CABLE

24 Strands 0.2mm Hookup Wire/Cable one Reel 100 Meters BROWN

FEATURES

• 24 strands/0.2 mm
• Tinned copper wire
• Insul ation PVC-V105
• O/D: 2.5mm
• Amps: 7.0A/240V
• For Electronics, Switchboards, etc.
• Colour: BROWN
• Per Reel

var evExternalHTML = ‘doss-hookup’;

RG6 QUAD SHIELD CABLE – 305M

METRE CODE:

Inner conductor is a copper clad steel wire within a gas injected polythene foam dielectric. The sheilding is 2 × screening of aluminium tape covered with woven aluminium braid outer conductor.

• 1.02mm copper clad steel centre conductor (Conductivity 20%)
• 2 × Aluminium 45% braid & 2 × Sealed APA tape
• Dielectric: 4.57mm Foam Polyethylene
• First Shield: Bonded AL Foil
• Second Shield: 45% AL Braiding
• Thrid Shield: AL/PET
• Fourth Shield: 45% AL Braiding
• Suitable for UHF, Pay, Satellite – Ø7.40mm Jacket
• Nominal Impedance: 75Ω ±3
• Nominal Velocity of Propagation: 85%
• Nominal Capacitance: 50pF/M
• Speaker Test: 4000V AC
• Attenuation (dB/100m):
  • 4.538 @ 55MHz
  • 8.522 @ 211MHz
  • 12.828 @ 450MHz
  • 18.254 @ 870MHz
  • 19.642 @ 1000MHz
  • 23.899 @ 1440MHz
  • 29.673 @ 2150MHz
  • 35.386 @ 3000MHz

Available In

• 305m Dispensing Box with Reversed Metre Marking (RG6QDB-305M)
• 100m Roll (RG6QDR-100M)
• 30m Roll (RG6QDR-30M)
• By the metre (RG6QDB-1M)

Downloads

pdf; 652kB Doss RG6QUAD attenuation report (100m)

pdf; 530kB Doss RG6QUAD attenuation report (30m)

RG11 QUAD SHIELD COAX CABLE-1M

• Cable construction (inner- to outer-most):
  • Core:
    • 14 AWG / Ø1.63mm
    • CCS (Copper Coated Steel) 21%
    • DC Resistance: 11Ω / 1000ft. at 20°C
  • Dielectric Foam PE: Ø7.11mm
  • Shielding:
    • Bonded Aluminium Foil
    • Braid Aluminium Shield:
      • 96x Ø0.16mm,
      • 60% Coverage
    • Non-bonded Aluminium Foil
    • Braid Aluminium Shield:
      • 64x Ø0.16mm,
      • 40% Coverage
    • Shield DC Resitance: 6.9Ω / 1000ft. at 20°C
  • PVC Jacket:
    • Ø10.3mm
    • Colour: Black
• Operating temperature range: -20 ~ 60°C
• Return loss: 15dB Max (100% swept tested)
• Impedance: 75.0Ω ± 3Ω
• Attenuation:
  • 0.20dB/100ft @ 1MHz
  • 0.50dB/100ft @ 10MHz
  • 0.95dB/100ft @ 50MHz
  • 1.25dB/100ft @ 100MHz
  • 1.75dB/100ft @ 200MHz
  • 2.45dB/100ft @ 400MHz
  • 3.35dB/100ft @ 700MHz
  • 3.8dB/100ft @ 900MHz
  • 4.00dB/100ft @ 1000MHz
  • 4.40dB/100ft @ 1200MHz
  • 4.80dB/100ft @ 1450MHz
  • 5.30dB/100ft @ 1800MHz
  • 5.80dB/100ft @ 2200MHz

RG11 QUAD SHIELD COAX CABLE

• Cable construction (inner- to outer-most):
  • Core:
    • 14 AWG / Ø1.63mm
    • CCS (Copper Coated Steel) 21%
    • DC Resistance: 11Ω / 1000ft. at 20°C
  • Dielectric Foam PE: Ø7.11mm
  • Shielding:
    • Bonded Aluminium Foil
    • Braid Aluminium Shield:
      • 96x Ø0.16mm,
      • 60% Coverage
    • Non-bonded Aluminium Foil
    • Braid Aluminium Shield:
      • 64x Ø0.16mm,
      • 40% Coverage
    • Shield DC Resitance: 6.9Ω / 1000ft. at 20°C
  • PVC Jacket:
    • Ø10.3mm
    • Colour: Black
• Operating temperature range: -20 ~ 60°C
• Return loss: 15dB Max (100% swept tested)
• Impedance: 75.0Ω ± 3Ω
• Attenuation:
  • 0.20dB/100ft @ 1MHz
  • 0.50dB/100ft @ 10MHz
  • 0.95dB/100ft @ 50MHz
  • 1.25dB/100ft @ 100MHz
  • 1.75dB/100ft @ 200MHz
  • 2.45dB/100ft @ 400MHz
  • 3.35dB/100ft @ 700MHz
  • 3.8dB/100ft @ 900MHz
  • 4.00dB/100ft @ 1000MHz
  • 4.40dB/100ft @ 1200MHz
  • 4.80dB/100ft @ 1450MHz
  • 5.30dB/100ft @ 1800MHz
  • 5.80dB/100ft @ 2200MHz

LL195 50OHM COAXIAL CABLE -1M

LL195 – 50 OHM COAXIAL CABLE

A heavy duty 50 ohm coaxial cable with 0.94mm±0.01solid bare copper conductor & Bonded dual al foil+ tinned copper outer conductor.

• Foam PE dielectric
• Black PVC sheathed.
• O/D: 4.95mm±0.13
• Cap.: 27PF/FT

Cable Construction

Attenuation

LL195 50OHM COAXIAL CABLE-100M

LL195 – 50 OHM COAXIAL CABLE

A heavy duty 50 ohm coaxial cable with 0.94mm±0.01solid bare copper conductor & Bonded dual al foil+ tinned copper outer conductor.

• Foam PE dielectric
• Black PVC sheathed.
• O/D: 4.95mm±0.13
• Cap.: 27PF/M

Cable Construction

Attenuation

LL400 50 OHM COAXIAL CABLE-1M

LL400 – 50 OHM COAXIAL CABLE

A heavy-duty 50Ω coaxial cable, suitable for low-loss applications such as mobile phone booster systems.

Mechanical Characteristics

• Impedance: 50 ± 2 Ω
• Velocity: 85%
• Minimum bend radius: 51.5mm
• Capacitance: 78.9pF/m
• Jacket spark: 8000 V_RMS

Construction

Attenuation Characteristics

LL400 50 OHM COAX CABLE-100M

LL400 – 50 OHM COAXIAL CABLE

A heavy-duty 50Ω coaxial cable, suitable for low-loss applications such as mobile phone booster systems.

Mechanical Characteristics

• Impedance: 50 ± 2 Ω
• Velocity: 85%
• Minimum bend radius: 51.5mm
• Capacitance: 78.9pF/m
• Jacket spark: 8000 V_RMS

Construction

Attenuation Characteristics
