RG6 QUAD SHIELD CABLE – 305M

METRE CODE:
Please note that this product is sold in ROLLS.
The product is also available in METERS. If you want to order the product in METERS, please use CODE 05052070

METRE CODE:

Inner conductor is a copper clad steel wire within a gas injected polythene foam dielectric. The sheilding is 2 × screening of aluminium tape covered with woven aluminium braid outer conductor.

Available In

Downloads

pdf; 652kB Doss RG6QUAD attenuation report (100m)
pdf; 530kB Doss RG6QUAD attenuation report (30m)

4 CORE SECURITY CABLE – 100M

RG59 AND FIG8 CCTV COMBO – 1M

Features

METRE CODE:
Please note that this product is sold in METRES.
Ensure that your order quantity matches your desired length (ie. 30 for 30m).
Length in brackets- eg. (100m) denotes available roll length.

Figure-8 RG59 Video Coax + heavy duty 2-core power cablewith tracer

Downloads

manualDownload the DOSS RG59UAttenuation Test Results (.pdf)

FAQs

Q. Can CCTV cameras operate over the full 100m length of the CCTV cable?

Yes. Picture remains excellent and there are no issueswith power.
Method:
We tested a Doss IN50PRO connected to a Doss 12VDC/500mA powersupply over the full 100m length.
We measured voltage input at 12.18V and output voltage at 10.38V.
Current draw was 260mA and resistance was 7 Ohms.

RG59 AND FIG8 CCTV COMBO – 100M

RG59 Video Coax, plus heavy duty 2 core fig. 8 camera power cable with tracer in tough outer sheath.. Designed for commercial applications.
– Overall: 10mmØ.
– 100 metre Reel

F/UTP CAT6A SOLID BLUE CABLE

This item is sold as a 305m roll

Need a shorter length?

This cable is also available per metre.

Features

Specifications

Conductor Material Bare Copper
Size 23AWG
1/0.56/0.58±0.015mm
Insulation Material HD-PE
Thickness MIN at any point: 0.24/ 0.28mm
MAX AVG: 0.26/0.3mm
Diameter 1.08±0.01mm; 1.15±0.01mm
Colour Code Blue/ White-Blue
Orange/White-Green
Green/ White-Green
Brown/ White-Brown
Elongation MIN 300%
Tensile strength MIN 1.682 Kg/mm2
Stranding Myar 0.025x23mm
Al Foil 0.065x23mm
Drain Wire 1/0.40±0.02mm
Cross Slot 5.0×0.7mm
Jacket Material CMR PVR
Thickness MIN at any point: 0.53mm
MAX AVG: 0.57mm
Diameter 7.4±0.2mm

F/UTP CAT6A SOLID BLUE CABLE1M

This item is sold per “METRE”

If you order 5, you will get five metres.

Need a longer length?

This cable is also available as a 305m roll.

Features

Specifications

Conductor Material Bare Copper
Size 23AWG
1/0.56/0.58 ±0.015mm
Insulation Material HD-PE
Thickness MIN at any point: 0.24/0.28mm
MAX AVG: 0.26/0.3mm
Diameter 1.08 ±0.01mm; 1.15 ±0.01mm
Colour Code
  • Blue/White-Blue
  • Orange/White-Green
  • Green/White-Green
  • Brown/White-Brown
Elongation MIN 300%
Tensile strength MIN 1.682Kg/mm²
Stranding Myar 0.025 × 23mm
Al Foil 0.065 × 23mm
Drain Wire 1/0.40 ±0.02mm
Cross Slot 5.0 × 0.7mm
Jacket Material CMR PVR
Thickness MIN at any point: 0.53mm
MAX AVG: 0.57mm
Diameter 7.4 ±0.2mm

SSTP CAT6 SOLID CABLE BLUE305M

This item is sold as a 305m roll

Need a shorter length?

This cable is also available per metre.

S/STP (Screened Shielded Twisted Pair) or S/FTP (ScreenedFoiled Twisted Pair) cabling offers shielding between the pair sets and an overall sheath shield within the cable. This type of shielding protects EMI from entering or exitingthe cable and also protects neighbouring pairs from crosstalk.

Specifications

Images

SSTP CAT6 SOLID BLUE -1M

This item is sold per “METRE”

If you order 5, you will get five metres.

Need a longer length?

This cable is also available as a 305 m roll.

S/STP (Screened Shielded Twisted Pair) or S/FTP (ScreenedFoiled Twisted Pair) cabling offers shielding between the pair sets and an overall sheath shield within the cable. This type of shielding protects EMI from entering or exitingthe cable and also protects neighbouring pairs from crosstalk.

Specifications

Images

UTP CAT6 SOLID BLUE – 1M

This item is sold per “METRE”

If you order 5, you will get five metres.

Need a longer length?

This cable is also available as a 305 m roll.

var cable_model = $(‘#ProductModel.ListValue’).text(); var cable_colour = “Blue”; var cable_sold_as = “metre”; var cable_roll_length = “305m”;

initDossCat6();

CAT5E STRANDED CORE -1M

This item is sold per “METRE”

If you order 5, you will get five metres.

Need a longer length?

This cable is also available as a 100 m roll.

Flex-plus plenum is a high performance category 5 cable, perfect for self-terminated, custom length patch leads.

CAT5E SOLID BLUE BOX -1M

BROADBAND READY CAT-5E UTP PATCH CABLE

METRE CODE:
Please note that this product is sold in METRES.
To order the reel, put in 305m in your order quantity. Otherwise ensure that your order quantity matches your desired length (ie. 30 for 30m).
Length in brackets- eg. (305m) denotes available roll length.
If other suppliers don’t have an "A-Tick" and the ACA supplier code on their Cat5e,don’t buy it! It cannot be legally connected to the Australian communication network!

  • Doss Cat5e is tested and exceeds the Australian requirements as presented in the Cat5e Test ReportsPDF file(Right-click and Save Link As to download the PDF file).
  • Our A-Tick supplier code is N1185.

Note: Non-approved product is available on the Australian market and is often less expensive due to the use of less copper or CCA, flammable PVC jackets or poorer production methods.

CAT5E UNAPPROVED CCA UTP-1M

Features

METRE CODE:
Please note that this product is sold in METRES.
To order the reel, put in 305m in your order quantity. Otherwise ensure that your order quantity matches your desired length (ie. 30 for 30m).
Length in brackets- eg. (305m) denotes available roll length.

This Unapproved CAT5E Solid-core UTP Cable is perfect for those installing CCTV systems and don’t want the cost of RG59U cabling.

With the use of Video and Power Baluns, video, audio and power can be sent over twisted pair cables at reduced cost to using RG59U Coaxial cables. Since video, audio and power don’t require the high specifications and bandwidth of 100TBASE and 1000TBASE network connections, DOSS has sourceda cable to reduce cost further, while still exceeding specifications required for twisted pair CCTV transmission.

While the cable is Unapproved for CAT5E applications, our tests indicate that it is still morethan adequate for short runs in wired network uses, however we do not recommend it nor provide any guarantee for networking uses.
WARNING:
IT IS ILLEGAL TO CONNECT THIS ITEM TO ANY TELECOMMUNICATIONS NETWORK OR FACILITY, UNLESS YOU HAVE PERMISSION.

Specifications

Example usage

FAQs

What’s the meaning of Unapproved?
In layman terms, if equipment has the provision to be connected to the internet, approved cable needs to be used. That means that even if it’s not connected to the internet, but there is some possibility to connect it, then approved cable is required.

PREMIUM COMPONENT CABLE – 1M

METRE CODE:
Please note that this product is sold in METRES.
Ensure that your order quantity matches your desired length (ie. 30 for 30m).
Length in brackets- eg. (100m) denotes available roll length.

PRORGB Component Video Cable – 1MT

  • Available as a 30 metre roll
  • Professional quality and durable construction

Specifications:

  • Inner conduct: 3x 1/0.5mm Cu
  • Inner insulation: 3x Ø 2.7mm FPE
  • Al/Mylar: 3x 10/0.025mm
  • Braid: 3x 112/0.12mm Cu
  • Cotton: 3x 50/0.25mm
  • Middle jack: Ø 5.0mm PVC (Red/ Blue/ Green)
  • Cotton paper: 25*0.05mm
  • Outer jack: Ø 14.0mm PVC

TRIO+ STEREO COAX CABLE – 1M

METRE CODE:
Please note that this product is sold in METRES.
Ensure that your order quantity matches your desired length (ie. 30 for 30m).
Length in brackets- eg. (100m) denotes available roll length.

RG59RGBTS WITH STEREO COAX CABLE

Features:

  • Ideal for professional, permanent AV installations (inside walls, under floors etc.)
  • RGB colour coded cores
  • Conductor use purest OFC, it has the characteristicsof high conductivity, low electric resistance, good signal transmission
  • Insulation uses foamed PE, which has low dielectricconstant, low capacitance, less attenuation and distortion, ensure signal quality and transmits image and sound signals with high stability and fidelity
  • Adopting double shield, aluminum foil + AL/Mg braiding, minimal circuit interference, high signal-to-noiseratio is obtained
  • Soft, highly flexible PVC outer jacket is vibration-resistant. It is free of signal quality deterioration caused by molding vibration and bending

Specifications:

  • Conductor: 5*1/Ø0.8mm OFC
  • Insulation: 5*Ø3.65mm Foamed PE
  • Lapping: 5*AL/Mylar
  • Braiding: 5*16/3/0.16mm AL/Mg
  • Jacket: 5*Ø6.0mm PVC
  • Wave impedance: 75±3 ohm(@200MHz)
  • Attenuation at 20C: 1 1~450MHz = 20dB/100m 450~862MHz = 30dB/100m 862~2150MHz = 45dB/100m
  • Capacity/m: 54±5pF

BLUE AUDIO/MIC CABLE 100M ROLL

This item is sold as a 100m roll

Need a shorter length?

This cable is also available per metre.

BLUE AUDIO / MIC CABLE – 1M

This item is sold per “METRE”

If you order 5, you will get five metres.

Need a longer length?

This cable is also available as a 100 m roll.

AUDIO / MIC CABLE – 100M

This item is sold as a 100m roll

Need a shorter length?

This cable is also available per metre.

  • 2 x 16/0.2mm tinned copper conducto
  • Braided tin ned copper wire shield
  • Black PVC sheath with cotton filler
  • Insul. Thickness: 0.3mm
  • O/D: 5.4mm

    • AUDIO / MIC CABLE – 1M

    This item is sold per “METRE”

    If you order 5, you will get five metres.

    Need a longer length?

    This cable is also available as a 100 m roll.

    DIGITAL CAR BATTERY TESTER

    Features

    Specifications

    Battery type Lead-acid battery
    Voltage measure range 7-16V
    Test range CCA/100-2000, DIN/100-1400, EN/100-2000, IEC/100-1400
      SAE/100-2000, JIS/26A17-245H52, GB/30-200AH
    Test category Battery test, Cranking test, Charging system test
    Test result Healthy, Electric quantity, Actual measurement, Resistance
    Working temperature -18°C to 50°C
    Material Acid resistant ABS plastic
    Test clip length 55cm
    Product size 145*75*24mm
    Product weight 232g

    Contents

    50 OHM RG58 STRANDED CABLE-1M

    This item is sold per “METRE”

    If you order 5, you will get five metres.

    Need a longer length?

    This cable is also available as a 100 m roll.

    50Ω RG58 Networking Cable
    A 50Ω co-axial cable for communications and computerconnection with 19 x 0.18mm stranded bare copper conductor, copper clad aluminum braided shield,Polyethylene dielectric and Black PVC sheathed.

    Communication Cableas used for computer networking

    Capacitance: 100PF/M

    Attenuation @ 200MHz – 23dB/100M

    O/D: 5mm

    Sold per metre

    50 OHM RG58 STRANDED – 100M

    This item is sold as a 100m roll

    Need a shorter length?

    This cable is also available per metre.

    50Ω RG58 Networking Cable
    A 50Ω co-axial cable for communications and computerconnection with 19 x 0.18mm stranded bare copper conductor, copper clad aluminum braided shield,Polyethylene dielectric and Black PVC sheathed.

    Communication Cableas used for PC networking

    Capacitance: 100PF/M

    Attenuation @ 200MHz – 23dB/100M

    O/D: 5mm

    Roll length 100 Metres

    QUAD SHIELD CABLE – 30M ROLL

    Doss RG6QUAD – 30m Roll

    Inner conductor is a copper clad steel wire within a gas injected polythene foam dielectric. The sheilding is 2 × screening of aluminium tape covered with woven aluminium braid outer conductor.

    Available In

    Downloads

    pdf; 652kB Doss RG6QUAD attenuation report (100m)
    pdf; 530kB Doss RG6QUAD attenuation report (30m)

    QUAD SHIELD RG6 – 100M ROLL

    Doss RG6QUAD – 100m Roll

    Inner conductor is a copper clad steel wire within a gas injected polythene foam dielectric. The sheilding is 2 × screening of aluminium tapecovered with woven aluminium braid outer conductor.

    Available In

    Downloads

    pdf; 652kB Doss RG6QUAD attenuation report (100m)
    pdf; 530kB Doss RG6QUAD attenuation report (30m)

    QUAD SHIELD RG6 CABLE 1M

    METRE CODE:
    Please note that this product is sold in METRES.
    The product is also available in ROLLS. If you want to order the product in ROLLS, please use CODE 05052100

    Inner conductor is a copper clad steel wire within a gas injected polythene foam dielectric. The sheilding is 2 × screening of aluminium tape covered with woven aluminium braid outer conductor.

    Available In

    Downloads

    pdf; 652kB Doss RG6QUAD attenuation report (100m)
    pdf; 530kB Doss RG6QUAD attenuation report (30m)

    RG59 COAX CABLE 100M

    This item is sold as a 100m roll

    Need a shorter length?

    This cable is also available per metre.

    1 x 0.8mm solid copper conductor with braided
    copper shield 75 ohm co-axial cable.
    -Black PVC sheathed
    -Overal l Diameter: 6.5mm
    -Attenuation @ 470MHz – 18dB/100M
    -100 metre Reel

    Specification

    manualDownload the DOSS RG59UAttenuation Test Results (.pdf)



    RG59 COAX CABLE 1M

    This item is sold per “METRE”

    If you order 5, you will get five metres.

    Need a longer length?

    This cable is also available as a 100 m roll.

    Specification

    manualDownload the DOSS RG59UAttenuation Test Results (.pdf)



    50 OHM RG213 STRANDED COAX100M

    RG213DB – 50 OHM COAXIAL CABLE

    A heavy duty 50 ohm coaxial cable with 7 x 0.752mm stranded plain copper conductor & braided shield.

    50 OHM RG213 STRANDED COAX-1M

    RG213DB – 50 OHM COAXIAL CABLE

    A heavy duty 50 ohm coaxial cable with 7 x 0.752mm stranded plain copper conductor & braided shield.



    METRE CODE:
    Please note that this product is sold in METRES.
    Ensure that your order quantity matches your desired length (ie. 30 for 30m).
    Length in brackets- eg. (100m) denotes available roll length.

    8 WAY ‘F’ SPLITTER OR COMBINER

    High quality satellite & cable TV compatible 75ohm splitters in zinc diecast housing.

        SP2F SP3F SP4F SP6F SP8F
        2-WAY 3-WAY 4-WAY 6-WAY 8-WAY
      Frequency Range (MHz) Nominal
    (dB)    		 Nominal
    (dB)    		 Nominal
    (dB)    		 Nominal
    (dB)    		 Nominal
    (dB)
    Insertion Loss

    5 – 40

    4.5

    6.9

    8.0

    12.5

    13.5

    40 – 1000

    4.5

    7.0

    8.5

    13.6

    13.6

    1000 – 1750

    5.5

    8.5

    9.8

    14.7

    16.0

    1750 – 2300

    7.2

    11.0

    12.6

    16.5

    18.0

    Isolation

    5 – 40

    14

    18

    20

    20

    20

    40 – 1000

    20

    21

    22

    22

    20

    1000 – 2300

    20

    22

    21

    21

    22


    Return Loss

    5 – 40

    14

    12

    12

    9

    9

    40 – 1000

    13

    16

    14

    13

    13

    1000 – 2050

    15

    14

    13

    13

    13

    2050 – 2300

    12

    12

    12

    12

    12

    Note:
    Doss splitters will also function as combiners.

    • When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
    • It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

    2 WAY ‘F’ SPLITTER FREE TO AIR

    Specifications:

        FSP2F FSP3F FSP4F FSP6F FSP8F
      Frequency Range(MHz) Nominal Nominal Nominal Nominal Nominal
    Insertion Loss 5-47MHz 4.2 5.8 8.2 11.5 12.5
    (Max dB) 48-450MHz 4.2 5.8 8.2 11.5 12.5
      451-750MHz 4.2 6.5 8.2 11.5 12.5
      751-900 MHz 4.2 7 8.2 11.5 12.5
    ISOLATION 5-47MHz 20 20 20 20 20
    Out-out 48-450MHz 20 20 20 20 20
    (Min dB) 451-750MHz 20 20 20 20 20
      751-900 MHz 20 20 20 20 20
    Return Loss 5-47MHz 18 18 18 16 18
    Input 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16
    Return Loss 5-47MHz 18 18 18 16 18
    Output 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16



    Note:
    Doss splitters will also function as combiners.

    • When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
    • It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

    4 WAY ‘F’ SPLITTER FREE TO AIR

    Specifications:

        FSP2F FSP3F FSP4F FSP6F FSP8F
      Frequency Range(MHz) Nominal Nominal Nominal Nominal Nominal
    Insertion Loss 5-47MHz 4.2 5.8 8.2 11.5 12.5
    (Max dB) 48-450MHz 4.2 5.8 8.2 11.5 12.5
      451-750MHz 4.2 6.5 8.2 11.5 12.5
      751-900 MHz 4.2 7 8.2 11.5 12.5
    ISOLATION 5-47MHz 20 20 20 20 20
    Out-out 48-450MHz 20 20 20 20 20
    (Min dB) 451-750MHz 20 20 20 20 20
      751-900 MHz 20 20 20 20 20
    Return Loss 5-47MHz 18 18 18 16 18
    Input 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16
    Return Loss 5-47MHz 18 18 18 16 18
    Output 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16

    Note:
    Doss splitters will also function as combiners.

    • When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
    • It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

    3 WAY ‘F’ SPLITTER FREE TO AIR FSP3FB

    Specifications:

        FSP2F FSP3F FSP4F FSP6F FSP8F
      Frequency Range(MHz) Nominal Nominal Nominal Nominal Nominal
    Insertion Loss 5-47MHz 4.2 5.8 8.2 11.5 12.5
    (Max dB) 48-450MHz 4.2 5.8 8.2 11.5 12.5
      451-750MHz 4.2 6.5 8.2 11.5 12.5
      751-900 MHz 4.2 7 8.2 11.5 12.5
    ISOLATION 5-47MHz 20 20 20 20 20
    Out-out 48-450MHz 20 20 20 20 20
    (Min dB) 451-750MHz 20 20 20 20 20
      751-900 MHz 20 20 20 20 20
    Return Loss 5-47MHz 18 18 18 16 18
    Input 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16
    Return Loss 5-47MHz 18 18 18 16 18
    Output 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16

    Note:
    Doss splitters will also function as combiners.

    • When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
    • It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

    6 WAY ‘F’ SPLITTER FREE TO AIR

    Specifications:

        FSP2F FSP3F FSP4F FSP6F FSP8F
      Frequency Range(MHz) Nominal Nominal Nominal Nominal Nominal
    Insertion Loss 5-47MHz 4.2 5.8 8.2 11.5 12.5
    (Max dB) 48-450MHz 4.2 5.8 8.2 11.5 12.5
      451-750MHz 4.2 6.5 8.2 11.5 12.5
      751-900 MHz 4.2 7 8.2 11.5 12.5
    ISOLATION 5-47MHz 20 20 20 20 20
    Out-out 48-450MHz 20 20 20 20 20
    (Min dB) 451-750MHz 20 20 20 20 20
      751-900 MHz 20 20 20 20 20
    Return Loss 5-47MHz 18 18 18 16 18
    Input 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16
    Return Loss 5-47MHz 18 18 18 16 18
    Output 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16

    Note:
    Doss splitters will also function as combiners.

    • When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
    • It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

    8 WAY ‘F’ SPLITTER FREE TO AIR

    Specifications:

        FSP2F FSP3F FSP4F FSP6F FSP8F
      Frequency Range(MHz) Nominal Nominal Nominal Nominal Nominal
    Insertion Loss 5-47MHz 4.2 5.8 8.2 11.5 12.5
    (Max dB) 48-450MHz 4.2 5.8 8.2 11.5 12.5
      451-750MHz 4.2 6.5 8.2 11.5 12.5
      751-900 MHz 4.2 7 8.2 11.5 12.5
    ISOLATION 5-47MHz 20 20 20 20 20
    Out-out 48-450MHz 20 20 20 20 20
    (Min dB) 451-750MHz 20 20 20 20 20
      751-900 MHz 20 20 20 20 20
    Return Loss 5-47MHz 18 18 18 16 18
    Input 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16
    Return Loss 5-47MHz 18 18 18 16 18
    Output 48-450MHz 18 18 18 16 18
    (Min dB) 451-750MHz 18 16 16 16 16
      751-900 MHz 18 16 16 16 16

    Note:
    Doss splitters will also function as combiners.

    • When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
    • It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

    TV MOUNT TILTING KIT

    Doss Bracket Range PDF

    A full range of brackets to mount your flat panel TV to yourdesk, wall or ceiling.
    View theentire range of Doss Brackets

    TV bracket tilting kit.

    Provides 0°-15° tilt for TV mounts.

    Kit including:

    1. 4 hooks for tilting mount
    2. 4 screws set (4*screws, 4*washers,4*nuts) to secure tilting kit on TV bracket.

    SECURITY DOOR BEAM / CHIME

    Infra-Red Door Beam

    Features:

    Applications:

    Specifications:

    COUNTER TO SUIT DES700 DEA7WL2

    Counter to suit NIR100SA Retro-Reflective Photoelectric Sensor Entry Alert System

    Includes the following:

    EXTENSION SPEAKER FOR DEA7WL2

    Extension Speaker

    Ideal for the DOSS Wireless Door Entry Alarm.

    Please refer to download tab for speaker pairing manual.

    Please note the extension speaker doesn’t come with the power supply.

    Specifications

    Wireless Door Announcer
    Type Microprocessor based control unit
    Housing ABS
    Radio Frequency 433.92MHz
    Wireless Coverage Range ≤100m (Open space)
    Volume of Speaker 0 ~ Max (Adjustable)
    Chime/Alarm Time 30 sec max. (Adjustable)
    Power input Jack DC Jack (f)5.5mm/2.1mm
    Power Supply 12V DC/130 mA SM1205 (Not included)
    Power output Jack Phone Jack (f)3.5mm
    Temperature 0°C ~ 50°C

    WIRELESS DOOR/BEAM ENTRY ALARM

    Features

    DEA7WL2 is a compact wireless entry alarm system which is easy to install indoor. It is designed for both residentialand commercial using such as garage door, shops, warehouse restaurants etc. to alert you to the entry of customers and visitors. The system consists of a send/receive unit which transmits an IR beam across the doorway onto a prismatic reflector mounted on the opposite side. The beam is reflected back to the receiver to complete the circuit. Whena person walks through the beam, the circuit is interrupted and this causes the alarm to sound an audible warning. The warning buzzer can be mounted in any suitable location.

    Planning on using it outdoors?

    It is not the recommended application. Installation under direct sunlight can be tricky and could result in decrease of reliability.

    Please refer to download tab for pairing instructions

    Features

    Specifications

    ’áPhotoelectric Beam Sensor
    Type
    Infrared Receiver Modules for Remote Control Systems
    Housing ABS
    Radio Frequency 433.92 MHz
    LED Emitting Element Infrared LED Indicator (Red)
    Sensing Range 0.5 ~ 7 meters (1.6 ft ~ 22 ft)
    Power Supply Switching mode power supply for sensor and speaker
    Current Drain (mA) Standby (Beam Aligned properly): 3.7 mA/Beam Broken:14 mA
    Power input wire DC Jack (f)5.5mm/2.1mm x (L)12cm
    Wireless Door Announcer
    Type Microprocessor based control unit
    Housing ABS
    Radio Frequency 433.92MHz
    Wireless Coverage Range ≤100m (Open space)
    Volume of Speaker 0 ~ Max (Adjustable)
    Chime/Alarm Time 30 sec max. (Adjustable)
    Power Supply (Input) AC / DC Adaptor (100-240VAC/50-60Hz)
    Power input Jack DC Jack (f)5.5mm/2.1mm
    Power Supply (Output) 12VDC/130 mA
    Power output Jack Phone Jack (f)3.5mm
    Temperature 0°C ~ 50°C
    4 Digits Counter (Optional)
    Type 4 Digits Counter (Number can be adjusted +/-/Reset)
    Housing ABS
    Power Supply 12VDC/ 130mA (same power source as speaker)
    Power input wire Phone Plug (f)3.5mm

    CCTV SECURITY SIGN

    Prominent warning sign for CCTV or dummy surveillance applications. Made by acrylic for durability. Easy for installation and maintenance. An ideal product for alerting people.

    Specifications
