WIRELESS DOOR/BEAM ENTRY ALARM

Features

DEA7WL2 is a compact wireless entry alarm system which is easy to install indoor. It is designed for both residentialand commercial using such as garage door, shops, warehouse restaurants etc. to alert you to the entry of customers and visitors. The system consists of a send/receive unit which transmits an IR beam across the doorway onto a prismatic reflector mounted on the opposite side. The beam is reflected back to the receiver to complete the circuit. Whena person walks through the beam, the circuit is interrupted and this causes the alarm to sound an audible warning. The warning buzzer can be mounted in any suitable location.

Planning on using it outdoors?

It is not the recommended application. Installation under direct sunlight can be tricky and could result in decrease of reliability.

Please refer to download tab for pairing instructions

Features

For using as an entrance indicator
No wiring required between the sensor and speaker
Upto 100m wireless range (open space)
When tripped, the sensor wirelessly transmits to any programmed speaker
Speaker makes “”ding-dong”” or siren sound when beam is interrupted
Speaker volume can be adjusted or turned off
When in siren mode, sounding time is adjustable from 3~30 seconds
Connect additional speakers to the sensor wirelessly (one speaker included)
Each sensor can be paired with unlimited number of speakers

Specifications

’áPhotoelectric Beam Sensor
Type	Infrared Receiver Modules for Remote Control Systems
Housing	ABS
Radio Frequency	433.92 MHz
LED Emitting Element	Infrared LED Indicator (Red)
Sensing Range	0.5 ~ 7 meters (1.6 ft ~ 22 ft)
Power Supply	Switching mode power supply for sensor and speaker
Current Drain (mA)	Standby (Beam Aligned properly): 3.7 mA/Beam Broken:14 mA
Power input wire	DC Jack (f)5.5mm/2.1mm x (L)12cm
Wireless Door Announcer
Type	Microprocessor based control unit
Housing	ABS
Radio Frequency	433.92MHz
Wireless Coverage Range	≤100m (Open space)
Volume of Speaker	0 ~ Max (Adjustable)
Chime/Alarm Time	30 sec max. (Adjustable)
Power Supply (Input)	AC / DC Adaptor (100-240VAC/50-60Hz)
Power input Jack	DC Jack (f)5.5mm/2.1mm
Power Supply (Output)	12VDC/130 mA
Power output Jack	Phone Jack (f)3.5mm
Temperature	0°C ~ 50°C
4 Digits Counter (Optional)
Type	4 Digits Counter (Number can be adjusted +/-/Reset)
Housing	ABS
Power Supply	12VDC/ 130mA (same power source as speaker)
Power input wire	Phone Plug (f)3.5mm

5-694MHZ 4G ANTENNA FILTER

The 700 MHz frequencies used by some 4G services are next to the frequencies used for FTA TV; there is a small chance this may cause disruption to FTA services. If you areexperiencing interference since your area retuned, this filter may assist in filtering out these signals.

Filters LTE/4G signals for interference free VHF/UHF
Installs inline
F-type Socket to F-type Socket
Pass-Band Insertion Loss: 5~694 MHz < 3dB
Stop-Band Insertion Rejection: 720 ~ 1000 MHz > 40dB

Click on images for larger version

Signal strength (dB) for the full TV spectrum

Signal strength (dB) for the end of the TV spectrum including 4G/LTE

3-IN 8-OUT MULTISWITCH

Doss SMS38F multiswitch can be used with a dual LNB to distribute satellite TV signals to multiple receivers from asingle dish and LNB. It features 3 input which means it allows you to combine a dual LNB plus an input from a terrestrial antenna.

This product saves the hassle of installing several satellite antennas for your multiple television subscribers needs.

It distributes your satellite system up to 8 output receivers.

Features

3 In ports (Dual LNB and Terrestrial antenna)
8 Out ports

Specification

Frequency Range:
- SAT : 950-2050 MHz
- Terrestrial : 5-862 MHz
Gain:
- SAT: 4dB
- Terrestrial: -16±1 dB
Current consumption on each output: 60mA
Max current to LNB: 400mA

2 WAY ‘F’ SPLITTER OR COMBINER

High quality satellite & cable TV compatible 75ohm splitters in zinc diecast housing.

“”F”” type connections designedto operate from 2GHz down to 5 MHz permitting use in interactive systems
Nickel plated zinc die-cast housings
Tongue & groove housing design provides high RFI shielding for ?120 dB
Frequency response of 5-2400 MHz
High precision machine threaded F-ports
Power pass 12 V DC, 500 mA all ports
Usable for special channels and return channels
Impedance: 75Ω
For both VHF and UHF frequencies
Built in grounding block
No IR passing
Can be used to combine
Output dB loss was tested @ 2050mHZ

		SP2F	SP3F	SP4F	SP6F	SP8F
		2-WAY	3-WAY	4-WAY	6-WAY	8-WAY
	Frequency Range (MHz)	Nominal (dB)	Nominal (dB)	Nominal (dB)	Nominal (dB)	Nominal (dB)
Insertion Loss	5 – 40	4.5	6.9	8.0	12.5	13.5
40 – 1000	4.5	7.0	8.5	13.6	13.6
1000 – 1750	5.5	8.5	9.8	14.7	16.0
1750 – 2300	7.2	11.0	12.6	16.5	18.0

Isolation	5 – 40	14	18	20	20	20
40 – 1000	20	21	22	22	20
1000 – 2300	20	22	21	21	22

Return Loss	5 – 40	14	12	12	9	9
40 – 1000	13	16	14	13	13
1000 – 2050	15	14	13	13	13
2050 – 2300	12	12	12	12	12

Note:
Doss splitters will also function as combiners.

When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

3 WAY ‘F’ SPLITTER OR COMBINER

High quality satellite & cable TV compatible 75ohm splitters in zinc diecast housing.

“”F”” type connections designedto operate from 2GHz down to 5 MHz permitting use in interactive systems
Nickel plated zinc die-cast housings
Tongue & groove housing design provides high RFI shielding for ?120 dB
Frequency response of 5-2400 MHz
High precision machine threaded F-ports
Power pass 12 V DC, 500 mA all ports
Usable for special channels and return channels
Impedance: 75Ω
For both VHF and UHF frequencies
Built in grounding block
No IR passing
Can be used to combine
Output dB loss was tested @ 2050mHZ

		SP2F	SP3F	SP4F	SP6F	SP8F
		2-WAY	3-WAY	4-WAY	6-WAY	8-WAY
	Frequency Range (MHz)	Nominal (dB)	Nominal (dB)	Nominal (dB)	Nominal (dB)	Nominal (dB)
Insertion Loss	5 – 40	4.5	6.9	8.0	12.5	13.5
40 – 1000	4.5	7.0	8.5	13.6	13.6
1000 – 1750	5.5	8.5	9.8	14.7	16.0
1750 – 2300	7.2	11.0	12.6	16.5	18.0

Isolation	5 – 40	14	18	20	20	20
40 – 1000	20	21	22	22	20
1000 – 2300	20	22	21	21	22

Return Loss	5 – 40	14	12	12	9	9
40 – 1000	13	16	14	13	13
1000 – 2050	15	14	13	13	13
2050 – 2300	12	12	12	12	12

Note:
Doss splitters will also function as combiners.

When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.

5-694MHZ 4G INLINE FILTER

Filters LTE/4G signals for interference free VHF / UHF
Installs inline
PAL Socket to PAL Plug
Pass-band Insertion Loss: 5~694MHz < 3dB
Stop-band Insertion Rejection: 720~1000MHz > 40dB

Click on images for larger version

Signal strength (dB) for the full TV spectrum

Signal strength (dB) for the TV spectrum including the4G LTE range

4 WAY ‘F’ SPLITTER OR COMBINER

High quality satellite & cable TV compatible 75ohm splitters in zinc diecast housing.

“”F”” type connections designedto operate from 2GHz down to 5 MHz permitting use in interactive systems
Nickel plated zinc die-cast housings
Tongue & groove housing design provides high RFI shielding for ?120 dB
Frequency response of 5-2400 MHz
High precision machine threaded F-ports
Power pass 12 V DC, 500 mA all ports
Usable for special channels and return channels
Impedance: 75Ω
For both VHF and UHF frequencies
Built in grounding block
No IR passing
Can be used to combine
Output dB loss was tested @ 2050mHZ

		SP2F	SP3F	SP4F	SP6F	SP8F
		2-WAY	3-WAY	4-WAY	6-WAY	8-WAY
	Frequency Range (MHz)	Nominal (dB)	Nominal (dB)	Nominal (dB)	Nominal (dB)	Nominal (dB)
Insertion Loss	5 – 40	4.5	6.9	8.0	12.5	13.5
40 – 1000	4.5	7.0	8.5	13.6	13.6
1000 – 1750	5.5	8.5	9.8	14.7	16.0
1750 – 2300	7.2	11.0	12.6	16.5	18.0

Isolation	5 – 40	14	18	20	20	20
40 – 1000	20	21	22	22	20
1000 – 2300	20	22	21	21	22

Return Loss	5 – 40	14	12	12	9	9
40 – 1000	13	16	14	13	13
1000 – 2050	15	14	13	13	13
2050 – 2300	12	12	12	12	12

Note:
Doss splitters will also function as combiners.

When combining modulated signals, leave at least a 2 channel separation i.e. Channel 21 for the first channel and Channel 24 for the next etc.
It is also recommended that if you also have an antenna connected to the system, you use a Digiair Pro when selecting the appropriate channels. The spectrum analyser function will display where there are the lowest levels of interference i.e. where the modulated should be placed in the radio spectrum.
