DM10IPMIC DOME 2.8MM LENS 1080P 10M IR IP CAMERA WITH MICROPHONE

DM10IPMIC DOME 2.8MM LENS 1080P 10M IR IP CAMERA WITH MICROPHONE

Additional Images

43161220

Features



Features

  • Max resolution 2Mega (1920×1080@30fps)
  • Support low bit rate, low delay and ROI enhance encoding
  • H. 265 high effective compression, save bandwidth and storage space
  • Support multi-line OSD
  • High effective IR leds, long service life, IR distance can reach 5-10m
  • Support Smart IR, prevent IR overexposure at night
  • ICR IR filter plate automatic switch, achieve real D/N monitoring
  • Support corridor mode, increase the monitoring area in longitudinal strip environment
  • Support Micro SD card (256G) local-storage
  • Support 3D digital N/R, DWDR



Specifications

Specifications

CAMERA
Image sensor 1/2.9" SONY 2.07 MP Progressive scan Exmor CMOS
Min.illumination 0Lux/F1.4 (IR ON) Color: 0.06Lux/F1.4, B/W: 0.01Lux/F1.4
IR distance 5-10M( 6x IR Leds)
Electronic shutter Auto/ Manual(1/25~1/10000), FLK
Day/ Night ICR switch, auto, color,  B/W, ext
Lens 2.8mm lens
Lens interface M12
Auto Iris /
S/N ratio =50db (AGC OFF)
Output  PAL/NTSC adjustable
WDR DWDR(Off/ Low/ Middle/ High)
Light board control Auto/ Manual/Off
3D N/R Off/ Low/ Middle/ High/ Higher
Defog Off/ Low/ Middle/ High
Mirror Off/ Horizontal/ Vertical/ 180º rotation/Corridor mode(90º rotation, 270º rotation)
Slow Shutter Off/ On
Exposure control Auto/ Manual
Image setting Brightness, Contrast, Saturation, Sharpness, Hue
AUDIO/VIDEO ENCODING
Video compression H.265/H.264/MJPEG
H.265 Encoding  Main Profile
H.264 Encoding  BaseLine / Main Profile / High Profile
Encoding features NTSC: main stream: 1920×1080@30fps, sub-stream: D1@30fps
PAL: main stream: 1920×1080@25fps, sub-stream: D1@25fps
Max. Resolution 1920X1080
Video bit rate Constant bit rate, variable bit rate (16kbps~8000kbps)
Video type Complex stream/ Video stream
Audio compression G.711u
Audio bit rate 64Kbps
Audio control Support input/output volume gain control
ROI  Support 4 zones, multi-stage level
Watermark function /
NETWORK
Network protocol TCP/IP, UDP, HTTP, DHCP, RTSP, DDNS, NTP, PPPoE, UPnP, SMTP, FTP
Access protocol ONVIF, GB28181 (optional)
Browser Support IE, Chrome, Firefox, Safari
Video preview meanwhile 3
User permission User add/ modify/ delete,  permission management
Safe mode Authorized user name and password, HTTPS encryption and AES link encryption, RTSP verification
Motion detection Set detection zone, Multi-level sensitivity can be set
Tampering alarm 1 zone
Privacy Mask 4 zones
Intelligent analysis /
Event linkage Snapshot, TF card video, FTP upload or Email sending, alarm output linkage, preset linkage
Multicast function Support
ANR Support, match with NVR
Mobile surveillance Support Apple, Android
Device exception detection Support network disconnected, IP conflict, illegal access alarm
OSD Title, time and date overlay, multi-line OSD
DST Support
Snapshot Support snapshot, snapshot resolution is encoding resolution
System update Support remote update
Other /
INTERFACE
Network Interface RJ45 10M/100M network adaptive
Analog video output 1CH 1.0Vp-p Composite video output
Audio  /
Alarm input /
Alarm output /
Reset /
RS485 /
TF card Support Max 256G, Micro SD(SDHC /SDXC) card local-storage
Microphone Support
Other /
GENERAL
Operating temperature -20°C ~ 55°C
Operating humidity 0?-90?
Protection grade /
Power supply DC12V /PoE optional
PoE   Optional
Power consumption (max) <6W
Dimensions(mm) 117(D)*66(H)mm
Weight/PCS(g) /
